Camozzi | QLM2A063A050M | 63mm Bore x 50mm Stroke | ISO 21287 | Pneumatic Cylinder
- Brand Camozzi
- MPNQLM2A063A050M
- Category ISO 21287 Compact Pneumatic Cylinder
Camozzi QLM2A063A050M is a Series QL double-acting ISO 21287 compact pneumatic cylinder with a 63mm bore and 50mm stroke, using G1/4 pneumatic ports.
This is the male-rod short-stroke configuration.
Construction uses anodised aluminium body, stainless steel piston rod and PU seals. Its ISO 21287 compact format reduces installation length while retaining a standardised mounting envelope.
| Manufacturer Part Number | QLM2A063A050M |
|---|---|
| Brand | Camozzi |
| Cylinder Type | ISO 21287 Compact Pneumatic Cylinder |
| Acting Type | Double Acting |
| Standard | ISO 21287 |
| Bore | 63mm |
| Stroke | 50mm |
| Series | Series QL |
| Product Configuration | Short-stroke cylinders male rod variant |
| Port Size | G1/4 |
| Body Material | Anodised aluminium |
| Rod Material | Stainless steel |
| Seal Material | PU |
| Weight | 950. g / pcs |
| GTIN | 8051707594691 |
Product quotation
Request a Quote
This quotation form is for orders of two or more of the selected cylinder. For a single cylinder, use the live website price and add the item directly to your basket. For larger quantities, submit your requirement and we will confirm current pricing, availability, build status and lead time.
Selected part
QLM2A063A050M
Manufacturer
Camozzi
Possible cylinder alternatives
These products match the available cylinder standard, bore, stroke and acting-type data. They are displayed in the technical order written by the Cylinder Warehouse alternatives automation.
Standard
ISO 21287
Bore
63mm
Stroke
50mm
Acting
Double Acting
Possible alternative only. Matching is based on the available product data. Confirm mounting dimensions, port size, cushioning, piston-rod thread, magnetic sensing, materials and the complete operating specification before ordering.
